SMD Pan Nut

POCONS PPN0112

SMD Pan Nut, 1.6 × 1.6 × 1.6 mm. Manufactured directly by POCONS — IATF 16949, no broker markup.

Download datasheet (PDF)Printable spec sheet

POCONS PPN0112 smd pan nut — CAD render, top view — CAD render from the POCONS factory model. Dimensions on the spec table are the controlled values.

POCONS PPN0112 smd pan nut — CAD render, underside view — CAD render from the POCONS factory model. Dimensions on the spec table are the controlled values.

Availability: standard catalog part. Pricing is quoted within one business day; sample requests are forwarded to the factory, and production lead time is confirmed on the quote.

POCONS PPN0112 specifications
Category	SMD Pan Nut
Type	SMD PAN NUT
Dimensions (L×W×H)	1.6 × 1.6 × 1.6 mm
Material
Plating	—
Packaging
Certification	IATF 16949 (automotive-grade)

Envelope drawing generated from catalog dimensions (L × W × H). Not a controlled drawing: feature geometry, tolerances and pad layout are on the factory drawing issued with samples.

From the factory datasheet

Catalog PDF · p.12 →

Factory datasheet values for POCONS PPN0112
Style	Round spacer
Bore	ø1.6
Outer diameter	Ø3.6 mm
Minimum order	10,000 pcs

Spec & Compliance

Engineering specifications and compliance
Attachment method	SMD

Full specification and compliance documentation is issued per part with samples. Request it for your part →

See where these shields are used: Applications by industry →

Where are you in the design cycle?

Concept / early designGet design support →PCB layoutRequest CAD & footprint →PrototypeRequest samples →Pre-complianceRequest samples + test data →ProductionRequest production quote & lead time →

Request the PPN0112

Samples, the datasheet, and pricing — direct from the manufacturer, IATF 16949.

Request Samples & Quote View spec sheet Browse full catalog

About the PPN0112

What is the POCONS PPN0112?

The PPN0112 is a POCONS smd pan nut measuring 1.6 × 1.6 × 1.6 mm, supplied . It is manufactured directly by POCONS (IATF 16949 certified).

How do I get samples or a quote for the PPN0112?

Request samples, the datasheet, and pricing through our contact form. POCONS manufactures direct — no broker markup or added lead time — and typically responds within one business day.
